Bulk Braided Fishing Line — PE Braid Manufacturer

Free sample, US stock

A 150 m Pro Grade Braid PE X8 retail spool ships free from our US stock so you can test the line on a reel before you order anything.

Factory direct since 2005

Spun, braided, dyed, coated and spooled under one roof — no trading house between your spec and the machine.

Measured, not inflated

Every batch is pull-tested on a calibrated bench, and the batch data goes out with the order on request.

Request a Bulk Quote

Specifications

Grades, strands, weave & coating

The spec sheet bends to your order. Mix strength grade, strand count, weave density and coating to hit your price point and performance target.

Fiber & strength grade

Raw material	Premium UHMWPE fiber — ultra-high molecular weight polyethylene for high strength and abrasion resistance.
Economic strength level	28–31 cN/dtex
Middle strength level	32–34 cN/dtex
High strength level	35–38 cN/dtex

Braid construction

Braided strands	X4 / X8 / X9 / X12 / X13 / X16
Plain weave	X4 / X8 / X12 / X16
Core-added structure	X9 (X8 + 1) · X13 (X12 + 1)

Weave density — PPI (picks per inch)

18–24 PPI · Economic (X4 / X8)	Looser weave, flatter profile — the value tier, more prone to fuzzing.
26–32 PPI · Mainstream (X8)	Tight weave, round line body — the everyday workhorse grade.
32–52 PPI · High Grade / Pro Tournament (X8 / X12 / X16)	Ultra-tight weave — round, thinner, stronger and smoother through the guides.

Coating

Normal PU coating	Standard finish — lower abrasion resistance, fades faster.
High-density nano coating	Stronger colorfastness and abrasion resistance; holds up under sun and friction.

Why PE braid

Five reasons braid outperforms mono

01 · Tensile performance

Higher breaking strength at the same diameter

Big pound-tests in a thin diameter, so the reel holds more line. Near-zero stretch sends the bite signal straight to your hand for fast hooksets, and the raw strength handles big fish, saltwater and pulling hard against structure.

02 · Diameter & casting

Thinner line, longer casts

At the same pound-test, PE runs far thinner than nylon. Less air and water drag means longer casts and a faster sink to find the fish-holding layer.

03 · Abrasion & environment

Abrasion resistant, non-absorbent

Outlasts nylon against rocks, sunken wood and pilings. It doesn't absorb water, so strength and diameter hold when wet — and it resists saltwater corrosion.

04 · Practical use

Low memory, high sensitivity

No coil for smooth line lay off the spool, and enough sensitivity to feel bottom structure and light bites. Suits lure, sea, boat and long-cast fishing, and makes ideal bulk-spool backing.

05 · Durability

Long shelf life, UV stable

Braid doesn't go brittle from UV the way nylon does. Long outdoor service life with slow performance loss over time.

Sizes & diameters

Diameter reference by grade

Each grade below has its own diameter-to-pound-test chart, from Ultra Thin X4 up to Standard X16 at 254 lb. Diameters in mm; strength in LB and KG test. Standard X16 is listed from 0.285 mm (60 lb); lighter X16 diameters may be made to order with their own minimum — we confirm availability in writing.

Ultra Thin X4

Size No	Diameter (mm)	LB test	KG test
0.03	0.020	5.07	2.30
0.05	0.045	5.73	2.60
0.08	0.049	9.26	4.20
0.1	0.053	10.80	4.90
0.2	0.074	12.13	5.50
0.3	0.090	13.01	5.90
0.4	0.104	13.67	6.20
0.6	0.128	15.65	7.10
0.8	0.148	16.31	7.40
1.0	0.165	18.08	8.20
1.2	0.180	20.06	9.10
1.5	0.205	27.56	12.50
2.0	0.235	31.53	14.30

Standard X4

Size No	Diameter (mm)	LB test	KG test
0.6	0.13	8.8	4.0
0.8	0.15	13.2	6.0
1.0	0.17	17.6	8.0
1.5	0.21	22.7	10.3
2.0	0.24	27.1	12.3
3.0	0.29	35.3	16.0
4.0	0.33	43.0	19.5
5.0	0.37	53.1	24.1
6.0	0.40	58.0	26.3

Economy X8

Size No	Diameter (mm)	LB test	KG test
0.8	0.15	18.10	8.20
1.0	0.17	22.10	10.00
1.5	0.21	27.10	12.30
2.0	0.24	31.10	14.10
3.0	0.29	40.00	18.00
4.0	0.33	48.10	21.80
5.0	0.37	57.50	26.10
6.0	0.40	62.40	28.30
7.0	0.45	73.90	33.50
8.0	0.50	79.00	35.80

Never Fade X8

Size No	Diameter (mm)	LB test	KG test
0.6	0.128	9.9	4.5
0.8	0.147	13.9	6.3
1.0	0.165	15.9	7.2
1.5	0.205	22.0	10.0
2.0	0.235	28.0	12.7
2.5	0.265	32.9	14.9
3.0	0.285	39.9	18.1
4.0	0.325	50.0	22.7
5.0	0.370	55.1	25.0
6.0	0.400	61.9	28.1
7.0	0.450	73.9	33.5
8.0	0.500	84.4	38.3
10.0	0.600	100.8	45.8

High Grade X8

Size No	Diameter (mm)	LB test	KG test
0.6	0.120	13.0	5.9
0.8	0.140	15.9	7.2
1.0	0.160	19.8	9.0
1.2	0.180	22.0	10.0
1.5	0.200	28.0	12.7
2.0	0.230	32.8	14.9
2.5	0.260	39.9	18.1
3.0	0.280	45.0	20.4
3.5	0.300	50.0	22.7
4.0	0.330	55.1	25.0
5.0	0.370	61.9	28.1
6.0	0.400	68.8	31.2
7.0	0.450	76.1	34.5
8.0	0.500	86.0	39.0

Standard X9

Size No	Diameter (mm)	LB test	KG test
0.8	0.140	15.4	7.0
1.0	0.160	18.7	8.5
1.5	0.200	20.3	9.2
2.0	0.230	22.0	10.0
2.5	0.260	34.8	15.8
3.0	0.280	37.3	16.9
3.5	0.300	41.0	18.6
4.0	0.330	50.7	23.0
5.0	0.370	61.7	28.0
6.0	0.400	70.8	32.1
7.0	0.450	81.1	36.8
8.0	0.500	88.8	40.3

Standard X12

Size No	Diameter (mm)	LB test	KG test
0.8	0.148	24.9	11.3
1.0	0.165	30.0	13.6
2.0	0.234	35.1	15.9
3.0	0.285	45.0	30.4
4.0	0.325	60.0	27.2
5.0	0.370	74.5	33.8
6.0	0.400	90.0	40.8
7.0	0.450	110.0	59.9
8.0	0.500	120.0	54.4
10.0	0.600	135.0	61.2

Standard X16

Size No	Diameter (mm)	LB test	KG test
3.0	0.285	60.0	27.0
4.0	0.325	77.0	35.0
5.0	0.370	95.0	43.0
6.0	0.400	110.0	50.0
7.0	0.450	128.0	58.0
8.0	0.500	137.0	62.0
10.0	0.600	163.0	74.0
12.0	0.700	190.0	86.0
15.0	0.800	220.0	100.0
20.0	0.900	254.0	115.0

Full size charts for every braided grade. Ask for the chart matching your target strand count and grade.

Straight answers

Private-label braid: what buyers ask

Do you make 8-strand and 16-strand braid for a standard and a premium range?

Yes. X8 is listed in three grades (Economy, Never Fade and High Grade) and X16 in the Standard X16 table, all from premium-grade UHMWPE fiber. Weave density runs from 18–24 PPI (economy) through 26–32 PPI (mainstream) to 32–52 PPI (high grade / pro tournament, X8 / X12 / X16), with standard PU or high-density nano coating. Strand count, weave density and coating are chosen per order.

Which strengths are listed for X8 and X16?

High Grade X8 is listed from 0.120 mm (13.0 lb / 5.9 kg) to 0.500 mm (86.0 lb / 39.0 kg); Never Fade X8 from 0.128 to 0.600 mm and Economy X8 from 0.15 to 0.50 mm. Standard X16 is listed from 0.285 mm (60.0 lb / 27.0 kg) to 0.900 mm (254.0 lb / 115.0 kg). Lighter X16 diameters are outside the published table and may be made to order with their own minimum. Send the strengths you want and we confirm availability in writing.

Can you wind retail spools under my brand, not just bulk spools?

Yes. Private-label runs are retail spools with your logo sticker or spool label, from 100 pieces per SKU. Spool length is set per order: our 150 m Pro Grade X8 retail spool is one existing example, and any other length you need is confirmed in the written quote. Braid boxes sized to spool length are shown on the packaging page.

What should I send for a private-label braid quote?

Strand count and grade, the diameters or pound tests, color, coating, retail spool length, quantity per SKU, packaging (label sticker or printed box) and delivery country. With those, the quote comes back as a spec sheet with a per-unit price, not a range.

Bulk braided fishing line, built to your spec
